#include <qgsrubberband.h>
Public Member Functions | |
QgsRubberBand (QgsMapCanvas *mapCanvas, bool isPolygon=false) | |
~QgsRubberBand () | |
void | setColor (const QColor &color) |
void | setWidth (int width) |
void | reset (bool isPolygon=false) |
void | addPoint (const QgsPoint &p, bool update=true, int geometryIndex=0) |
Add point to rubberband and update canvas If adding more points consider using update=false for better performance geometryIndex is the index of the feature part (in case of multipart geometries). | |
void | removeLastPoint (int geometryIndex=0) |
Removes the last point. Most useful in connection with undo operations. | |
void | movePoint (const QgsPoint &p, int geometryIndex=0) |
void | movePoint (int index, const QgsPoint &p, int geometryIndex=0) |
Moves the rubber band point specified by index. | |
void | setToGeometry (QgsGeometry *geom, QgsVectorLayer *layer) |
Sets this rubber band to the geometry of an existing feature. | |
void | addGeometry (QgsGeometry *geom, QgsVectorLayer *layer) |
Add the geometry of an existing feature to a rubberband This is useful for multi feature highlighting. | |
void | setTranslationOffset (double dx, double dy) |
Adds translation to original coordinates (all in map coordinates). | |
int | size () const |
Returns number of geometries added in 1.5. | |
int | numberOfVertices () const |
Returns count of vertices in all lists of mPoint. | |
const QgsPoint * | getPoint (int i, int j=0) const |
Return vertex. | |
QgsGeometry * | asGeometry () |
Returns the rubberband as a Geometry. | |
Protected Member Functions | |
virtual void | paint (QPainter *p) |
void | updateRect () |
recalculates needed rectangle | |
Private Member Functions | |
QgsRubberBand () | |
Static Private Member Functions | |
static QgsPolyline | getPolyline (const QList< QgsPoint > &points) |
Private Attributes | |
QBrush | mBrush |
QPen | mPen |
QList< QList< QgsPoint > > | mPoints |
Nested lists used for multitypes. | |
bool | mIsPolygon |
double | mTranslationOffsetX |
double | mTranslationOffsetY |
The QgsRubberBand class provides a transparent overlay widget for tracking the mouse while drawing polylines or polygons.
digitising lines) on the map.
Definition at line 32 of file qgsrubberband.h.
QgsRubberBand::QgsRubberBand | ( | QgsMapCanvas * | mapCanvas, | |
bool | isPolygon = false | |||
) |
QgsRubberBand::~QgsRubberBand | ( | ) |
Definition at line 41 of file qgsrubberband.cpp.
QgsRubberBand::QgsRubberBand | ( | ) | [private] |
Definition at line 38 of file qgsrubberband.cpp.
void QgsRubberBand::setColor | ( | const QColor & | color | ) |
Set the outline and fill color.
Definition at line 47 of file qgsrubberband.cpp.
Referenced by QgsRubberBand().
void QgsRubberBand::setWidth | ( | int | width | ) |
void QgsRubberBand::reset | ( | bool | isPolygon = false |
) |
Remove all points from the shape being created.
Definition at line 66 of file qgsrubberband.cpp.
References mIsPolygon, mPoints, and updateRect().
Referenced by QgsRubberBand(), and setToGeometry().
void QgsRubberBand::addPoint | ( | const QgsPoint & | p, | |
bool | do_update = true , |
|||
int | geometryIndex = 0 | |||
) |
Add point to rubberband and update canvas If adding more points consider using update=false for better performance geometryIndex is the index of the feature part (in case of multipart geometries).
Add a point to the shape being created.
Definition at line 77 of file qgsrubberband.cpp.
References mPoints, size(), and updateRect().
Referenced by addGeometry().
void QgsRubberBand::removeLastPoint | ( | int | geometryIndex = 0 |
) |
Removes the last point. Most useful in connection with undo operations.
Definition at line 108 of file qgsrubberband.cpp.
References mPoints, size(), and updateRect().
void QgsRubberBand::movePoint | ( | const QgsPoint & | p, | |
int | geometryIndex = 0 | |||
) |
Update the line between the last added point and the mouse position.
Definition at line 127 of file qgsrubberband.cpp.
References mPoints, and updateRect().
void QgsRubberBand::movePoint | ( | int | index, | |
const QgsPoint & | p, | |||
int | geometryIndex = 0 | |||
) |
Moves the rubber band point specified by index.
Note that if the rubber band is not used to track the last mouse position, the first point of the rubber band has two vertices
Definition at line 145 of file qgsrubberband.cpp.
References mPoints, and updateRect().
void QgsRubberBand::setToGeometry | ( | QgsGeometry * | geom, | |
QgsVectorLayer * | layer | |||
) |
Sets this rubber band to the geometry of an existing feature.
This is useful for feature highlighting.
geom | the geometry object | |
layer | the layer containing the feature, used for coord transformation to map crs. In case of 0 pointer, the coordinates are not going to be transformed. |
Definition at line 163 of file qgsrubberband.cpp.
References addGeometry(), mIsPolygon, and reset().
void QgsRubberBand::addGeometry | ( | QgsGeometry * | geom, | |
QgsVectorLayer * | layer | |||
) |
Add the geometry of an existing feature to a rubberband This is useful for multi feature highlighting.
geom | the geometry object | |
layer | the layer containing the feature, used for coord transformation to map crs. In case of 0 pointer, the coordinates are not going to be transformed. |
Definition at line 169 of file qgsrubberband.cpp.
References addPoint(), QgsGeometry::asMultiPoint(), QgsGeometry::asMultiPolygon(), QgsGeometry::asMultiPolyline(), QgsGeometry::asPoint(), QgsGeometry::asPolygon(), QgsGeometry::asPolyline(), QgsMapCanvas::extent(), QgsMapRenderer::layerToMapCoordinates(), QgsMapCanvas::mapRenderer(), mIsPolygon, QgsMapCanvasItem::mMapCanvas, mPoints, updateRect(), QgsRectangle::width(), QGis::WKBLineString, QGis::WKBLineString25D, QGis::WKBMultiLineString, QGis::WKBMultiLineString25D, QGis::WKBMultiPoint, QGis::WKBMultiPoint25D, QGis::WKBMultiPolygon, QGis::WKBMultiPolygon25D, QGis::WKBPoint, QGis::WKBPoint25D, QGis::WKBPolygon, QGis::WKBPolygon25D, QgsGeometry::wkbType(), QGis::WKBUnknown, QgsPoint::x(), and QgsPoint::y().
Referenced by setToGeometry().
void QgsRubberBand::setTranslationOffset | ( | double | dx, | |
double | dy | |||
) |
Adds translation to original coordinates (all in map coordinates).
Definition at line 400 of file qgsrubberband.cpp.
References mTranslationOffsetX, mTranslationOffsetY, and updateRect().
int QgsRubberBand::size | ( | void | ) | const |
Returns number of geometries added in 1.5.
Definition at line 407 of file qgsrubberband.cpp.
References mPoints.
Referenced by addPoint(), and removeLastPoint().
int QgsRubberBand::numberOfVertices | ( | ) | const |
Returns count of vertices in all lists of mPoint.
Definition at line 412 of file qgsrubberband.cpp.
References mPoints.
const QgsPoint * QgsRubberBand::getPoint | ( | int | i, | |
int | j = 0 | |||
) | const |
QgsGeometry * QgsRubberBand::asGeometry | ( | ) |
Returns the rubberband as a Geometry.
added in 1.6
Definition at line 435 of file qgsrubberband.cpp.
References QgsGeometry::fromMultiPolyline(), QgsGeometry::fromPolygon(), QgsGeometry::fromPolyline(), getPolyline(), mIsPolygon, and mPoints.
void QgsRubberBand::paint | ( | QPainter * | p | ) | [protected, virtual] |
Draw the shape in response to an update event.
Implements QgsMapCanvasItem.
Definition at line 338 of file qgsrubberband.cpp.
References mBrush, mIsPolygon, mPen, mPoints, mTranslationOffsetX, mTranslationOffsetY, and QgsMapCanvasItem::toCanvasCoordinates().
void QgsRubberBand::updateRect | ( | ) | [protected] |
recalculates needed rectangle
Definition at line 368 of file qgsrubberband.cpp.
References mPoints, mTranslationOffsetX, mTranslationOffsetY, and QgsMapCanvasItem::setRect().
Referenced by addGeometry(), addPoint(), movePoint(), removeLastPoint(), reset(), and setTranslationOffset().
QgsPolyline QgsRubberBand::getPolyline | ( | const QList< QgsPoint > & | points | ) | [static, private] |
QBrush QgsRubberBand::mBrush [private] |
QPen QgsRubberBand::mPen [private] |
QList< QList <QgsPoint> > QgsRubberBand::mPoints [private] |
Nested lists used for multitypes.
Definition at line 101 of file qgsrubberband.h.
Referenced by addGeometry(), addPoint(), asGeometry(), getPoint(), movePoint(), numberOfVertices(), paint(), removeLastPoint(), reset(), size(), and updateRect().
bool QgsRubberBand::mIsPolygon [private] |
Definition at line 102 of file qgsrubberband.h.
Referenced by addGeometry(), asGeometry(), paint(), reset(), and setToGeometry().
double QgsRubberBand::mTranslationOffsetX [private] |
Definition at line 103 of file qgsrubberband.h.
Referenced by paint(), setTranslationOffset(), and updateRect().
double QgsRubberBand::mTranslationOffsetY [private] |
Definition at line 104 of file qgsrubberband.h.
Referenced by paint(), setTranslationOffset(), and updateRect().
